DMD1050 Satellite Modem Board Rear Panel Interface
J1
ASYNC &
RLLP
J2 DATA
INTERFACE
MIL 188-114A
HW1
BATTERY
J7
INPUT
POWER
2
J8
SMA
FEMALE
J11
RJ45
Ethernet
Data
J10
RJ45
M&C
Figure 4-4. DMD1050 Bottom View
MN-DMD1050 4–4
Revision 9
