Concept2 SkiErg User Manual

13
1210
1530
m
32
s
/
m
1:55
1:53.2
1 Lane 7
4 Lane 4
5 Lane 1
6 peterd
ave
W a tt
+23m
+ 9m
-12m
/500
More Options
The More Options menu provides the following functions and utilities:
• Display Drag Factor:Dragfactorisameasureoffanload.ThePMself-calibratesbyrecalculating
the drag factor every stroke so you get a true measure of your effort regardless of the damper
setting or changing conditions. The drag factor is the most accurate way of setting your gearing.
• Utilities: Allows you to re-set the date, time or language. You can also adjust the contrast of the
LCD, check battery status and add workouts to the Custom List.
• Connect Heart Rate:(PM4only)Suunto™,Garmin
®
orANT+™heartratechestbeltscanbe
usedtodisplayandrecordyourheartrate.EachchestbelthasauniqueIDnumber.Usethis
menu to select your chest belt’s ID number. Save your ID number to a LogCard to have the
LogCardautomaticallyrecognizeyourchestbelt(forfutureworkouts).
For more information, visit concept2.com/heartrate.
• Memory/LogCard: ThePMstoresworkoutsintwoways.IfnoLogCard
ispresent,thePMwillstoreyourmostrecentworkoutsinMemory. The
oldest are automatically deleted. If a LogCard is inserted before a workout,
the workout data is stored on the LogCard, which stores approximately 300
workouts. The LogCard enables you to track your total and monthly meters
andyourperformanceduringeachsplitorintervalofyourworkout(including
heart rate, if available). You can view your workouts listed by date or by type.
Workout data can be moved from Memory to LogCard.
• Switch Users: Enables you to switch from one user to another on a shared LogCard.
Additional information is available at concept2.com and c2forum.com.
Information
Overview •
PM Details •
How to Ski •
Drag Factor •
More •
PM3
ThePM3usestwoalkalineD-Cell(LR20)
batteries. When you are skiing, the
ywheelprovidesaportionofthepower
to extend battery life.
PM4
Comes equipped with rechargeable battery pack. Recharge rate depends
on usage pattern of skier: the more and harder you ski, the more quickly
thePM4charges.Undercertainusagepatterns,itmaybebettertouse
twoalkalineD-Cell(LR20)batteries.
MayalsoberechargedbyconnectingPM4toPCusingUSBcable.
Refer to concept2.com/pm4 for more info.
BATTERY INFORMATION
Race Display
5-8 racers
Race leader
Racer just ahead of you
You
Racer just behind you
Meters
ahead(+)
orbehind(-)
Position
in race
OnepersoncreatestheraceontheirPM4byfollowingthe
PM4menu;othersjoininusingtheirownPM4.Theracecreator
is always in Lane 1 and starts the race when all are ready.
Remaining lane numbers are assigned based on order of entry
into the race. The race screen displays names for racers using
LogCards.
Biathlon: This game simulates the Olympic sport of Biathlon.
Row intervals that alternate with target shooting or another
activity.Choosefromarangeofpenaltydistances.ThePM
keeps track of your “range” time and your total elapsed time.
IfusingSuunto™chestbelts,youmustusecablestorace.Incertain
environmentswhereotherdevices(WiFi,Bluetooth,etc.)areinuse,Concept2
suggests use of cables. Only one wireless race can be in progress at a time.
Information/Help
ThePMcontainson-boardinformationtohelpyouifthemanualisnotavailable.
This section includes a brief skiing lesson with an animation of proper skiing
technique, an explanation of the Drag Factor, information about batteries and
more. We encourage you to press the Information button from the Main Menu
and read through the information provided.
Monthly Totals Judy
Dec 7:44:40 88260
Nov 3:04:10 34880
Oct 7:37:50 89000
Sep 8:40:50 100950
Aug 47:10 9050
July :00 0
Jun 1:44:50 21050
May 5:59:10 72160
Apr 9:09:30 109390
Mar 8:32:10 99260
Feb 7:20 1500
Jan 1:55:10 21570
Summary •
Month Totals •
List by Date •
List by Type •
LogCard Utilities •
LogCard
More Options
Display Drag Factor •
Utilities •
Connect Heart Rate •
Suunto, Garmin or ANT+ HR
Memory/Logcard •
Switch User •

Concept2 SkiErg Specifications

General

Resistance Type	Air resistance
Monitor	PM5
Drive Mechanism	High-strength cords
Power Requirements	2 D cell batteries
Maximum User Weight	227 kg (500 lb)
Construction	Steel and aluminum
Storage	Can be stored upright
Display Metrics	Time, distance, pace, calories, watts, stroke rate
Space Recommended for Use	61 cm x 122 cm (24 in x 48 in)
Warranty	2-year limited warranty
