2 Specifications
2.1 Feature List
Table 4 Feature Summary
Form Factor
Based on COM Express™ standard pinout Type 6 Rev. 3.0 (Compact size 95 x 95 mm)
Processor
11
th
Generation Intel
®
Core™ i7,i5, i3 and Celeron
®
Single Chip IOT UP3 Processors
Memory
Two memory sockets (located on the top and bottom side of the conga-TC570) with support for:
- SO-DIMM non-ECC DDR4 modules
- Data rates up to 3200 MTps
- Maximum 64 GB capacity (32 GB each)
- InBand ECC
1
(out-of-band ECC is not supported)
Chipset
Intel
®
500 Series PCH-LP integrated in the Multi-Chip Package
Audio
High Definition Audio interface with support for multiple codecs
Ethernet
Intel
®
i225 LM/V/IT 2.5 GbE controller with support for TSN
Graphics Options
Intel
®
Iris
®
Xe (Gen. 12). Supports:
- API (DirectX 12, Direct3D 12, Direct3D 2015, OpenGL 4.5, OpenCL 2.2)
- Intel
®
QuickSync & Clear Video Technology HD (hardware accelerated video decode/encode/processing/transcode)
- Up to four independent displays (see table 10 “Display Combination and Resolution”)
3x DP++ (DP/HDMI/DVI)
1x LVDS/eDP
2
1x PEG x4 port (PCIe Gen 4)
1x VGA
3
Resolutions up to 4x4K @ 60 Hz
Peripheral
Interfaces
8x USB 2.0 (Up to 4x USB 3.2 Gen 2x1)
Up to 2x SATA
®
6 with RAID 0/1/5 (shared with PCIe5 and PCIe6)
4
Up to 8x PCI Express
®
Gen. 3 lanes
4
2x UART (16C550 compatible)
GPIOs
LPC
I²C (fast mode, multi-master)
SMB
SPI
BIOS
AMI Aptio
®
V UEFI 2.x firmware
32 MB serial SPI flash with congatec Embedded BIOS features
Power
Management
ACPI 4.0a compliant with battery support.
S5e mode (see section 6.1.7 “Enhanced Soft-Off State”)
Deep Sx and Suspend to RAM (S3)
Configurable TDP
congatec Board
Controller
Multi-stage watchdog, non-volatile user data storage, manufacturing and board information, board statistics, hardware monitoring, fan control, I2C
bus, Power loss control
Security
Discrete SPI Trusted Platform Module (Infineon SLB9670VQ2.0); AES Instructions
