Copyright © 2021 congatec GmbH TCTLm02 44/67
Table 14 Connector C–D Pinout
Pin Row C Pin Row D Pin Row C Pin Row D
C1 GND (FIXED) D1 GND (FIXED) C56 PEG_RX1- D56 PEG_TX1-
C2 GND D2 GND C57 TYPE1#
1
D57 TYPE2#
C3 USB_SSRX0- D3 USB_SSTX0- C58 PEG_RX2+ D58 PEG_TX2+
C4 USB_SSRX0+ D4 USB_SSTX0+ C59 PEG_RX2- D59 PEG_TX2-
C5 GND D5 GND C60 GND (FIXED) D60 GND (FIXED)
C6 USB_SSRX1- D6 USB_SSTX1- C61 PEG_RX3+ D61 PEG_TX3+
C7 USB_SSRX1+ D7 USB_SSTX1+ C62 PEG_RX3- D62 PEG_TX3-
C8 GND D8 GND C63 RSVD D63 RSVD
1
C9 USB_SSRX2- D9 USB_SSTX2- C64 RSVD D64 RSVD
1
C10 USB_SSRX2+ D10 USB_SSTX2+ C65 PEG_RX4+
1
D65 PEG_TX4+
1
C11 GND (FIXED) D11 GND (FIXED) C66 PEG_RX4-
1
D66 PEG_TX4-
1
C12 USB_SSRX3- D12 USB_SSTX3- C67 RAPID_SHUTDOWN
1,2
D67 GND
C13 USB_SSRX3+ D13 USB_SSTX3+ C68 PEG_RX5+
1
D68 PEG_TX5+
1
C14 GND D14 GND C69 PEG_RX5-
1
D69 PEG_TX5-
1
C15 DDI1_PAIR6+
1
D15 DDI1_CTRLCLK_AUX+ C70 GND (FIXED) D70 GND (FIXED)
C16 DDI1_PAIR6-
1
D16 DDI1_CTRLDATA_AUX-
3
C71 PEG_RX6+
1
D71 PEG_TX6+
1
C17 RSVD D17 RSVD C72 PEG_RX6-
1
D72 PEG_TX6-
1
C18 RSVD D18 RSVD C73 GND D73 GND
C19 PCIE_RX6+ D19 PCIE_TX6+ C74 PEG_RX7+
1
D74 PEG_TX7+
1
C20 PCIE_RX6- D20 PCIE_TX6- C75 PEG_RX7-
1
D75 PEG_TX7-
1
C21 GND (FIXED) D21 GND (FIXED) C76 GND D76 GND
C22 PCIE_RX7+ D22 PCIE_TX7+ C77 RSVD
1
D77 RSVD
1
C23 PCIE_RX7- D23 PCIE_TX7- C78 PEG_RX8+
1
D78 PEG_TX8+
1
C24 DDI1_HPD D24 RSVD C79 PEG_RX8-
1
D79 PEG_TX8-
1
C25 DDI1_PAIR4+
1
D25 RSVD C80 GND (FIXED) D80 GND (FIXED)
C26 DDI1_PAIR4-
1
D26 DDI1_PAIR0+ C81 PEG_RX9+
1
D81 PEG_TX9+
1
C27 RSVD D27 DDI1_PAIR0- C82 PEG_RX9-
1
D82 PEG_TX9-
1
C28 RSVD D28 RSVD
1
C83 RSVD
1
D83 RSVD
1
C29 DDI1_PAIR5+
1
D29 DDI1_PAIR1+ C84 GND D84 GND
C30 DDI1_PAIR5-
1
D30 DDI1_PAIR1- C85 PEG_RX10+
1
D85 PEG_TX10+
1
C31 GND (FIXED) D31 GND (FIXED) C86 PEG_RX10-
1
D86 PEG_TX10-
1
C32 DDI2_CTRLCLK_AUX+ D32 DDI1_PAIR2+ C87 GND D87 GND
