5.1.3 Display Interfaces
The conga-TC570 offers the following display interfaces:
• three DP++ (DP/HDMI/DVI)
• dual-channel LVDS
• one VGA on commercial variants
• optional VGA on industrial variants
• four independent displays (DP++, eDP/LVDS and VGA)
The table below shows the supported display combinations and resolutions.
Table 10 Display Combination and Resolution
Display 1 (DDI1) Display 2 (DDI2) Display 3 (DDI3) Graphic 4
Interface Max. Resolution Interface Max. Resolution Interface Max. Resolution Interface Graphics
Option 1 DP++ 4096x2304 @
60 Hz, 36 bpp
DP++ 4096x2304 @
60 Hz, 36 bpp
DP++ 4096x2304 @
60 Hz, 36 bpp
LVDS or
eDP
1920x1200 @ 60 Hz (dual LVDS mode)
4096x2304 @ 60 Hz, 24 bpp
Option 2 DP++ 4096x2304 @
60 Hz, 36 bpp
DP++ 4096x2304 @
60 Hz, 36 bpp
DP++ 4096x2304 @
60 Hz, 36 bpp
VGA 1920x1200 @ 60 Hz
Option 3 DP++ 4096x2304 @
60 Hz, 36 bpp
DP++ 4096x2304 @
60 Hz, 36 bpp
VGA 1920x1200 @ 60 Hz LVDS or
eDP
1920x1200 @ 60 Hz (dual LVDS mode)
4096x2304 @ 60 Hz, 24 bpp
Note
A single DP/eDP display supports maximum resolution of 5120x3200 @ 60 Hz.
5.1.3.1 DP++
The conga-TC570 offers three DP++ interfaces. The interfaces support:
• three indepent DP displays (DP++)
• VESA DisplayPort Standard 1.2
• data rate of 1.62 GT/s, 2.97 GT/s and 5.4 GT/s on 1, 2 or 4 data lanes
• up to 4096x2304 resolutions at 60 Hz
• Audio formats such as AC-3 Dolby Digital, Dolby Digital Plus, DTS-HD, LPCM, 192 KHz/24 bit, 8 channel, Dolby TrueHD, DTS-HD Master
Audio (Lossless Blu-Ray Disc Audio Format)
