5.1.3.2 LVDS/eDP

The conga-TC570 offers an LVDS/eDP interface. This interface is conﬁgured in the BIOS to support LVDS by default. For eDP support, go to

Advanced -> Graphics -> Active LFP Conﬁguration in the BIOS setup menu and select “eDP”.

The LVDS

interface supports:

• single or dual channel LVDS (color depths of 18 bpp or 24 bpp)

• integrated ﬂat panel interface with clock frequency up to 112 MHz

• VESA and OpenLDI LVDS color mappings

• automatic panel detection via Embedded Panel Interface based on VESA EDID

1.3

• resolution up to 1920x1200 in dual LVDS channel mode

The eDP

1,2

interface supports:

• eDP 1.4 speciﬁcation

• Spread-Spectrum Clocking

• eDP display authentication

Note

The LVDS/eDP interface does not support both LVDS and eDP signals at the same time.

The eDP interface does not support HDCP

5.1.3.3 VGA

The Intel

Tiger Lake IoT UP3 SoC does not natively support VGA interface. However, the conga-TC570 commercial variants support this

interface by integrating a DisplayPort to VGA adapter chip.

Note

For VGA support on industrial variants, you need a customized conga-TC570 variant.
