Table 15 PCI Express Signal Descriptions (General Purpose)
Signal Pin # Description I/O PU/PD Comment
PCIE_RX0+
PCIE_RX0-
B68
B69
PCI Express channel 0, Receive Input differential pair I PCIE
PCIE_TX0+
PCIE_TX0-
A68
A69
PCI Express channel 0, Transmit Output differential pair O PCIE
PCIE_RX1+
PCIE_RX1-
B64
B65
PCI Express channel 1, Receive Input differential pair I PCIE
PCIE_TX1+
PCIE_TX1-
A64
A65
PCI Express channel 1, Transmit Output differential pair O PCIE
PCIE_RX2+
PCIE_RX2-
B61
B62
PCI Express channel 2, Receive Input differential pair I PCIE
PCIE_TX2+
PCIE_TX2-
A61
A62
PCI Express channel 2, Transmit Output differential pair O PCIE
PCIE_RX3+
PCIE_RX3-
B58
B59
PCI Express channel 3, Receive Input differential pair I PCIE
PCIE_TX3+
PCIE_TX3-
A58
A59
PCI Express channel 3, Transmit Output differential pair O PCIE
PCIE_RX4+
PCIE_RX4-
B55
B56
PCI Express channel 4, Receive Input differential pair I PCIE
PCIE_TX4+
PCIE_TX4-
A55
A56
PCI Express channel 4, Transmit Output differential pair O PCIE
PCIE_RX5+
PCIE_RX5-
B52
B53
PCI Express channel 5, Receive Input differential pair I PCIE Shared with SATA port 1 and configurable via the BIOS setup
menu
PCIE_TX5+
PCIE_TX5-
A52
A53
PCI Express channel 5, Transmit Output differential pair O PCIE
PCIE_RX6+
PCIE_RX6-
C19
C20
PCI Express channel 6, Receive Input differential pair I PCIE Shared with SATA port 0 and configurable via the BIOS setup
menu
PCIE_TX6+
PCIE_TX6-
D19
D20
PCI Express channel 6, Transmit Output differential pair O PCIE
PCIE_RX7+
PCIE_RX7-
C22
C23
PCI Express channel 7, Receive Input differential pair I PCIE Shared with USB 3.2 Gen 1x2, port 3 and configurable via the
BIOS setup menu
PCIE_TX7+
PCIE_TX7-
D22
D23
PCI Express channel 7, Transmit Output differential pair O PCIE
PCIE_CLK_REF+
PCIE_CLK_REF-
A88
A89
PCI Express Reference Clock output for all PCI Express
and PCI Express Graphics Lanes
O PCIE A PCI Express Gen2/3 compliant clock buffer chip must be
used on the carrier board if the design involves more than
one PCI Express device.
Note
The default BIOS setting for the shared ports is PCIe.
