Pin Row C Pin Row D Pin Row C Pin Row D
C33 DDI2_CTRLDATA_AUX-
3
D33 DDI1_PAIR2- C88 PEG_RX11+
1
D88 PEG_TX11+
1
C34 DDI2_DDC_AUX_SEL D34 DDI1_DDC_AUX_SEL C89 PEG_RX11-
1
D89 PEG_TX11-
1
C35 RSVD
1
D35 RSVD
1
C90 GND (FIXED) D90 GND (FIXED)
C36 DDI3_CTRLCLK_AUX+ D36 DDI1_PAIR3+ C91 PEG_RX12+
1
D91 PEG_TX12+
1
C37 DDI3_CTRLDATA_AUX-
3
D37 DDI1_PAIR3- C92 PEG_RX12-
1
D92 PEG_TX12-
1
C38 DDI3_DDC_AUX_SEL D38 RSVD
1
C93 GND D93 GND
C39 DDI3_PAIR0+ D39 DDI2_PAIR0+ C94 PEG_RX13+
1
D94 PEG_TX13+
1
C40 DDI3_PAIR0- D40 DDI2_PAIR0- C95 PEG_RX13-
1
D95 PEG_TX13-
1
C41 GND (FIXED) D41 GND (FIXED) C96 GND D96 GND
C42 DDI3_PAIR1+ D42 DDI2_PAIR1+ C97 RVSD
1
D97 RSVD
1
C43 DDI3_PAIR1- D43 DDI2_PAIR1- C98 PEG_RX14+
1
D98 PEG_TX14+
1
C44 DDI3_HPD D44 DDI2_HPD C99 PEG_RX14-
1
D99 PEG_TX14-
1
C45 RSVD
1
D45 RSVD
1
C100 GND (FIXED) D100 GND (FIXED)
C46 DDI3_PAIR2+ D46 DDI2_PAIR2+ C101 PEG_RX15+
1
D101 PEG_TX15+
1
C47 DDI3_PAIR2- D47 DDI2_PAIR2- C102 PEG_RX15-
1
D102 PEG_TX15-
1
C48 RSVD
1
D48 RSVD
1
C103 GND D103 GND
C49 DDI3_PAIR3+ D49 DDI2_PAIR3+ C104 VCC_12V D104 VCC_12V
C50 DDI3_PAIR3- D50 DDI2_PAIR3- C105 VCC_12V D105 VCC_12V
C51 GND (FIXED) D51 GND (FIXED) C106 VCC_12V D106 VCC_12V
C52 PEG_RX0+ D52 PEG_TX0+ C107 VCC_12V D107 VCC_12V
C53 PEG_RX0- D53 PEG_TX0- C108 VCC_12V D108 VCC_12V
C54 TYPE0#
1
D54 PEG_LANE_RV# C109 VCC_12V D109 VCC_12V
C55 PEG_RX1+ D55 PEG_TX1+ C110 GND (FIXED) D110 GND (FIXED)
Note
1.
Not connected
2.
Not supported
3.
Bootstrap signals
To Next Page
