Copyright © 2021 congatec GmbH TCTLm02 48/67
Signal Pin # Description I/O PU/PD Comment
PEG_RX10+
PEG_RX10-
C85
C86
PCI Express Graphics differential pairs 10
Note: Can also be used as PCI Express differential pairs 26
I PCIE Not connected
PEG_TX10+
PEG_TX10-
D85
D86
O PCIE
PEG_RX11+
PEG_RX11-
C88
C89
PCI Express Graphics differential pairs 11
Note: Can also be used as PCI Express differential pairs 27
I PCIE
PEG_TX11+
PEG_TX11-
D88
D89
O PCIE
PEG_RX12+
PEG_RX12-
C91
C92
PCI Express Graphics differential pairs 12
Note: Can also be used as PCI Express differential pairs 28
I PCIE
PEG_TX12+
PEG_TX12-
D91
D92
O PCIE
PEG_RX13+
PEG_RX13-
C94
C95
PCI Express Graphics differential pairs 13
Note: Can also be used as PCI Express differential pairs 29
I PCIE
PEG_TX13+
PEG_TX13-
D94
D95
O PCIE
PEG_RX14+
PEG_RX14-
C98
C99
PCI Express Graphics differential pairs 14
Note: Can also be used as PCI Express differential pairs 30
I PCIE
PEG_TX14+
PEG_TX14-
D98
D99
O PCIE
PEG_RX15+
PEG_RX15-
C101
C102
PCI Express Graphics differential pairs 15
Note: Can also be used as PCI Express differential pairs 31
I PCIE
PEG_TX15+
PEG_TX15-
D101
D102
O PCIE
PEG_LANE_RV# D54 PCI Express Graphics lane reversal input strap. Pull low on the carrier board to
reverse lane order.
I Not supported
Note
The conga-TC570 supports only PEG ports 0-3.
