4-2
4.5.3 Output Power
1) Equipment Requirements:
a) Monopolar Footswitch
b) Bipolar Footswitch
c) Commercial ESU Tester (e.g. Fluke 454A
or equivalent) with non-inductive 50
and 300 ohm loads for bipolar modes
and a non-inductive 500 ohm load for
monopolar modes.
Note: Micro Bipolar is particularly sensitive to
the load resistance. A 50 ohm load should be
used for checking power to obtain the best
results.
2) Use test leads to connect the ESU tester to
the unit’s return electrode output and the
footswitch controlled active output. Set the
Load resistance per mode as indicated in
Tables 4.1 and 4.2.
3) Perform the monopolar power tests indicated
in Tables 4.1 and 4.2. The acceptance range is
given in both Watts and Amps to accommo-
date available test equipment. It is not neces-
sary to test for both power and current.
Table 4.1 Monopolar Cut Mode RF Output Power Accuracy
Mode Load (ohms) Power Setting Watts (min) Watts (max) Amps (min) Amps (max)
Pure 500 20 17 23 0.184 0.214
500 100 90 110 0.424 0.469
500 300 270 330 0.735 0.812
Blend 500 20 17 23 0.184 0.214
500 100 90 110 0.424 0.469
500 200 180 220 0.600 0.663
Table 4.2 Monopolar Coag Mode RF Output Power Accuracy
Mode Load (ohms) Power Setting Watts (min) Watts (max) Amps (min) Amps (max)
Standard 500 20 17 23 0.184 0.214
500 50 45 55 0.300 0.332
500 120 108 132 0.465 0.514
Spray 500 20 17 23 0.184 0.214
500 50 45 55 0.300 0.332
500 80 72 88 0.379 0.420
4) Disconnect the ESU tester from the unit.
5) Use test leads to connect the ESU tester to
the Bipolar Accessory outputs.
6) Perform the bipolar power tests indicated in
Table 4.3. This table only provides the mini-
mum number of points to be tested.
Table 4.3 Bipolar Mode RF Output Power Accuracy
Mode Load (ohms) Power Setting Watts (min) Watts (max) Amps (min) Amps (max)
Macro 300 20 17 23 0.238 0.277
300 50 45 55 0.387 0.428
300 70 63 77 0.458 0.507
Spray 50 20 17 23 0.583 0.678
50 50 45 55 0.949 1.049
50 70 63 77 1.122 1.241
