• Press the Tone Loudness Adjustment Down
Key again and the configuration DIP switch
settings will be displayed. “0” is for OFF and
a “1” is for ON.
The eight-position configuration DIP switch (S2),
located on the Control/Display Board Assembly
allows a qualified service technician to change
some of the factory default settings. The default
switch is only read during Power on Self Test
(POST) or when the system is powered on, so
any changes to the switch positions should be
made with the main power off. Each switch is
OFF in the down position and ON in the up
position. Relevant information for each switch is
described in Table 4.9 and the positions are illus-
trated in Figure 4.2.
Table 4.9 DIP Switch Settings
Config.
Switch
Position
Title / Display
Element
Default Description for
Off
Description for On
1 TEST / Cut 100’s Off Run Mode.
Required position
for surgery.
Activates Test Mode, which inhibits most
of the system level monitoring for trouble-
shooting purposes. When this switch is
ON, both Bipolar Mode Select Keys on
the Display Panel must be pressed until
888 appears in the Monopolar Cut Power
Digital Display and the software revision
appears in the Monopolar Coag Power
Digital Display. 888 and the software revi-
sion may persist in the displays for a few
seconds after the Bipolar Mode Select Keys
are released. If both Bipolar Mode Select
Keys are not pressed, and Err 100 is dis-
played and the power must be cycled.
2 CAL/ Cut 10’s Off Run Mode.
Required position
for surgery.
Required for calibration of output power
and A.R.M. When this switch is ON,
both Bipolar Mode Select Keys on the
Display Panel must be pressed until [AL
appears in the Monopolar Cut Power
Digital Display and the software revision
appears in the Monopolar Coag Power
Digital Display. [AL and the software revi-
sion may persist in the displays for a few
seconds after the Bipolar Mode Select Keys
are released. If both Bipolar Mode Select
Keys are not pressed, and Err 100 is dis-
played and the power must be cycled.
3 SCOAG / Cut 1’s On Allows activation
of only one acces-
sory at a time
in Coagulation
modes.
Allows simultaneous activation of two
accessories for Coagulation modes.
4 DCUT / Coag
100’s
Off Allows activation
of only one acces-
sory at a time in
Cut modes.
Allows simultaneous activation of two
accessories for Cut modes.
