ConMed System 2450 - Page 29

4-19
Err
Code
Description Possible Cause Things to check Correction
107 Monitor boot-
load program
does not match
controller ROM
table
The program transmitted from
the System Controller to the
Monitor through the HPI
port at startup is faulty. This
could be caused by damage to
components associated with
the HPI bus on the Controller,
permitting electromagnetic
interference to upset one of the
processors.
Cycle system power and deter-
mine if this error is repeated.
Replace the Control/
Display Board.
108 RF TOKEN not
incremented, RF
controller pro-
gram corrupted
The program transmitted from
the System Controller to the
RF Controller through the HPI
port at startup is faulty or has
been corrupted after initializa-
tion. This could be caused by
damage to components associ-
ated with the HPI bus on the
Controller, permitting electro-
magnetic interference to upset
one of the processors.
Cycle system power and deter-
mine if this error is repeated.
Replace the Control/
Display Board.
109 Communications
lost during
POST tests
Communications through
the HPI port are faulty. This
could be caused by damage to
components associated with
the HPI bus on the Controller,
permitting electromagnetic
interference to upset one of the
processors.
Cycle system power and deter-
mine if this error is repeated.
Replace the Control/
Display Board.
112 Pre-activation
handshake,
monitor does
not read an acti-
vation signal
The activation signals detected
by the System Controller and
the Monitor do not match.
Cycle system power and deter-
mine if this error is repeated.
Replace the Control/
Display Board.
113 Pre-activation
handshake,
monitor does
not read a tone
signal
Prior to enabling electrosurgical
output power, the Monitor
ensures that an activation tone
is present. This error occurs if
the activation tone is not pres-
ent when the Monitor checks
prior to enabling electrosurgical
output power.
Increase the tone volume by
adjusting the Volume Control on
the back panel of the generator.
Cycle system power and deter-
mine if this error is repeated.
Configure system for test mode
operation. Check the tone drive
signal from the Control/Display
Board while the unit is activated.
Lack of a signal indicates a prob-
lem with the Control/Display
Board. Check for a proper
TONE_ MON signal to the con-
troller. Lack of a signal indicates
a problem with the Power Board.
Replace the Control/
Display Board.
Replace the Power
Board.
