Err
Code
Description Possible Cause Things to Check Correction
352 Monitor sensed
4x over power
condition for short
period
Excessive power at the
electrosurgical output was
detected for a short period
of time.
Recalibrate the system.
Configure the system for test
mode operation and cycle power.
Measure the actual power into a
fixed load.
If power is correct, verify proper
operation of the Monitor voltage
and current sensing circuits.
If power is correct, verify proper
operation of the RF Controller
voltage and current sensing cir-
cuits, the HVPS, and the RF
Amplifier.
Repair or Replace
the HVPS.
Repair or Replace
the RF Amplifier.
Repair or Replace
the RF Transformer
board.
Repair or Replace
the RF output
board.
Replace the
Controller assembly.
357 Monitor sensed
power @ 0W dial
power setting
The Monitor has sensed
electrosurgical output power
during activation while the
power is set to zero.
Recalibrate the system.
Configure the system for test
mode operation and cycle power.
Measure the actual power into a
fixed load.
If power is correct, verify proper
operation of the Monitor voltage
and current sensing circuits.
If power is correct, verify proper
operation of the RF Controller
voltage and current sensing cir-
cuits, the HVPS, and the RF
Amplifier.
Repair or Replace
the HVPS.
Repair or Replace
the RF Amplifier.
Repair or Replace
the RF Transformer
board.
Repair or Replace
the RF output
board.
Replace the
Controller assembly.
358 Monitor sensed
gate drive in idle
@ 0W dial power
setting
The Monitor has detected a
drive signal while the system
is not activated.
Cycle system power and deter-
mine if this error is repeated.
Replace the
Controller assembly.
359 Monitor sensed
peak voltages above
the LAP Limit
The Monitor has detected
voltage peaks in excess of
the limits while the system
is activated in Lap Advanced
Specialty mode.
Recalibrate the system.
Configure the system for test
mode operation and cycle power.
Measure the actual power into a
fixed load.
If power is correct, verify proper
operation of the Monitor voltage
and current sensing circuits.
If power is correct, verify proper
operation of the RF Controller
voltage and current sensing cir-
cuits, the HVPS, and the RF
Amplifier.
Repair or Replace
the HVPS.
Repair or Replace
the RF Amplifier.
Repair or Replace
the RF Transformer
board.
Repair or Replace
the RF output
board.
Replace the
Controller assembly.
360 Monitor program
counter landed on
an unused interrupt
vector
Monitor processor anomaly. Cycle system power and deter-
mine if this error is repeated.
Replace the
Controller assembly.
371 Monitor will
not disable RF
waveform on the
Controller assembly
during POST
POST has determined that
the Monitor cannot disable
the RF waveform.
Cycle system power and deter-
mine if this error is repeated.
Replace the
Controller assembly.
