What to do if 'Err xxx' appears on the display of ConMed SYSTEM 5000 Medical Equipment?
If an Err code appears on the display of your ConMed Medical Equipment, try cycling the power. If the error reappears, the unit should be taken out of service until a qualified biomedical engineer can diagnose the problem.
What to do if Single and Dual Dispersive Electrode Status / Alarm Indicators flash alternating red on ConMed Medical Equipment?
If the Single and Dual Dispersive Electrode Status / Alarm Indicators are flashing alternating red on your ConMed Medical Equipment, it could mean that a Dispersive Electrode is not connected to the system, a Dual Dispersive Electrode is connected but not properly applied to the patient, or a Dispersive Electrode is connected to the System but not properly seated. Ensure the connector is fully seated in the Two-Pin Dispersive Electrode Receptacle.
How to fix a blank display panel on ConMed Medical Equipment when powered on?
If the display panel is blank when your ConMed Medical Equipment system is powered on, verify the power cord is fully seated in the power receptacle on the back of the system. With the power cord disconnected, verify fuses are good and are installed properly in the receptacles on the back panel of the generator. Remove the top cover and verify that the controller board and all harnesses are properly seated. Check the Low Voltage Power Supply for +5V and +15V.
Why does my ConMed SYSTEM 5000 Medical Equipment have no output power?
If your ConMed Medical Equipment has no output power, it could be due to one or more bad connections inside the system, low voltage power supplied to A6 being bad, a shorted RF Amplifier power MOSFET, HVPS output being too low, or improper gate drive.
Why is the monopolar output incorrect on my ConMed SYSTEM 5000 Medical Equipment?
If you are experiencing incorrect monopolar output with your ConMed Medical Equipment, it could be due to bad calibration. Recalibrate and ensure the load resistor is correct when checking output power. Another cause could be bad voltage or current feedback.
Why is the bipolar output incorrect on my ConMed SYSTEM 5000 Medical Equipment?
If you are experiencing incorrect bipolar output with your ConMed Medical Equipment, it could be due to bad calibration. Recalibrate and ensure the load resistor is correct when checking output power. Another possible cause is bad voltage or current feedback.
What does 'A[[ xxx' on ConMed Medical Equipment display mean?
The 'A[[ xxx' error on your ConMed Medical Equipment display indicates an accessory error. This could be due to a faulty accessory being connected, a hand-controlled accessory being erroneously actuated, or a footswitch being erroneously actuated. Ensure that footswitches are not stacked on top of one another.
What does 'A[[ [P xx' on ConMed SYSTEM 5000 Medical Equipment display mean?
The 'A[[ [P xx' error on your ConMed Medical Equipment display indicates a control panel error. Check for a faulty push button on the front control panel, a control panel push button that has been pushed while the unit is being turned on, or a faulty cable connection between the front panel and the display board.
What do flashing decimal points on ConMed SYSTEM 5000 display mean?
Flashing decimal points on the display of your ConMed Medical Equipment indicate that the system is in Test Mode.
How to clear 'LF[ xxx' on ConMed SYSTEM 5000 display?
To clear the 'LF[ xxx' condition on your ConMed Medical Equipment display, the generator must be reset.
Details the two-year warranty, contact numbers for service, and legal information.
Explains key functional parameters for each operational mode, including Cut, Coag, and Bipolar modes.
Describes how mains power is converted to electrosurgical output through various system components.
Details configurable settings via dipswitches on the controller board, affecting system behavior.
Recommends periodic inspection and performance testing to ensure safe and effective operation.
Specifies that only qualified biomedical engineers should perform service on the unit.
Provides instructions for unit disassembly and reassembly, including cautions about static electricity.
Details how to clean the interior and exterior of the unit using appropriate methods and materials.
Outlines checks for power cord, connectors, external damage, and debris at least every six months.
Instructions to measure resistance between power plug ground and equipotential ground connection.
Procedure to verify proper operation of displays, alarms, and commands as per Section 2.3.1.
Details equipment and procedures for testing monopolar and bipolar output power accuracy across various loads.
Explains RF leakage hazards and presents allowable leakage currents to ground for various configurations.
Details procedures and limits for measuring line frequency leakage currents to neutral and ground.
Verifies correct operation of the A.R.M. circuit by testing its response to known resistances.
Details how to check output coupling capacitor values for Monopolar and Bipolar modes.
Explains how to enter calibration mode and the initial display indications for calibration status.
Details how to select modes and perform calibration for Monopolar, Bipolar, and A.R.M.™ systems.
Provides procedures for accessing stored error codes and clearing the fault memory.
Explains how to view system configuration DIP switch settings without removing the top cover.
Details how to use DACview in Test Mode to output internal system readings to a DVM or oscilloscope.
Lists potential errors, their causes, and recommended troubleshooting steps or corrections.
Addresses issues like no output power, low voltage supply problems, and MOSFET failure.
Emphasizes safety when working with high voltage, including using isolation transformers.
Provides guidance on checking LEDs, fuses, gate drive signals, and feedback resistors for HVPS issues.
Lists required information for ordering parts and obtaining return authorization from CONMED.
Lists numeric fault codes, their descriptions, possible causes, checks, and corrections.
Continues the list of fault codes, providing further diagnostic information and corrective actions.
General| Type | Electrosurgical Generator |
|---|---|
| Display | Digital |
| Input Voltage | 100-240 VAC |
| Line Frequency | 50/60 Hz |
| Modes | Cut, Coag |
| Safety Features | Return Electrode Monitoring (REM) |
| Footswitch | Optional |
