DETAILED FEATURE DESCRIPTION
Anvil Embedded System NVIDIA® Jetson AGX Orin™ Module Connector
The NVIDIA® Jetson AGX Orin™ processor and chipset are implemented on the Jetson AGX Orin™
Module. This connects to the AGX Orin module to the Anvil Embedded System via Molex Mirror Mezz
699 pin connector.
Function
Description
Location
Within The Anvil Embedded System
Type
Module
Pinout
Refer to NVIDIA® Jetson AGX Orin™
Datasheet.
Features
Refer to NVIDIA® Jetson AGX Orin™
Datasheet.
Note: A Thermal Transfer Plate is incorporated on the NVIDIA® Jetson AGX Orin™ module that dissipates heat through the top
of the The Anvil Embedded System Chassis.
