INTRODUCTION
Built to deploy massive AI workloads at the Edge, the Anvil Embedded System is the AI supercomputer
guaranteed to stay cool - even at Jetson AGX Orin™ MAX-N mode. The Anvil Embedded System can
withstand even the most compute intensive AI applications with its power-efficient and feature rich
design. Seamlessly deploy your next generation autonomous vehicle, smart city application, or
intelligent vision solution with this state-of-the-art NVIDIA Jetson AGX Orin™.
Product Features and Specifications
Specifications
Product Name
Anvil Embedded System
Module Compatibility
NVIDIA® Jetson AGX Orin™
Mechanical Dimensions
177.8 mm x 177.8 mm x 107.95 mm (7” x 7” x 4.25”)
USB
1x USB 3.2 (Connector: Type-C)
1x USB 3.0 w/ OTG (Connector: Type-C)
1x USB 3.0 + 2.0 Port to M.2 B-Key
1x USB 2.0 to M.2 E-Key
GMSL Cameras (with JCB add-on)
8x GMSL 1/2 Camera Inputs (Connector: 2x Quad Micro COAX)
Deserializers
Networking
2x 10G BASE-T
2x 1000BASE-T
Storage
2x NVMe (M.2 2280 M-KEY)
1x uSD Card Slot
Wireless Expansion
1x WiFi Module (M.2 2230 E-KEY)
1x LTE Module (M.2 3042 B-KEY) w/ SIM Card (3FF)
Video Output
1x DisplayPort++ (HDMI supported with compatible adapter)
Misc. I/O
2x levels UART1 and UART2 @ 3.3V
2x RS-232/485 UARTs
2x I2C Channel @ 3.3V IO
2x SPI Channel @ 3.3V IO
4x 3.3V GPI Inputs
6x 3.3V GPO Outputs (2x PWM Capable)
1x 3.3V Power Pin at 1A
CAN
2x Non-Isolated CAN 2.0b
RTC Battery
Included (CBG136)
Buttons
Power, Reset and Force Recovery buttons
Power Input
+10V to +36V DC Power Input (Mini-Fit Jr. 4-Pin Locking)
Operating Temperature
-25 C to +60 C (with 100% fan PWM or 8 m/s airflow)
Weight
TBD
