DISPLAYPORT Video Output
The Forge supports one DISPLAYPORT capable of 4k output resolution.
Connectors
Function
Display Output
Location
P5
Type
Full size DisplayPort connector
Connector
Part Number:
Manufacturer:
Mating
Cable
Standard DISPLAYPORT or DISPLAYPORT to
HDMI adapter cable
Pinout
As per DISPLAYPORT
Notes
The DISPLAYPORT output is capable of supporting HDMI using a DP++ compliant cable
adapter.
