POWER CONSUMPTION & THERMALS
The Anvil Embedded System has an Operating Temperature Range of -25°C to +60°C.
It is important to note that the NVIDIA® Jetson AGX Orin™ module has its own properties separate to
that of the peripherals. Customer responsibility requires proper implementation of a thermal solution
that maintains the Anvil Embedded System Passive cooling temperatures below the system maximums.
NVIDIA® Jetson AGX Orin™
Parameter
Value
Units
Maximum Jetson AGX Orin™ SoC Operating Temperature Top of Case
80
°C
Jetson AGX Orin™SoC Internal Maximum Temperature
99
°C
Parameter
Value
Units
Value
Units
Temperature
The Anvil Embedded System Theoretical Maximum
12
V
170
W (max)
25°C (typ.)
The Anvil Embedded System, NVIDIA® Jetson AGX
Orin™ Module MAXN mode, 100% CPU, 100% GPU,
100% 1x NVMe(s), 1x WiFi, 10G Eth loopback, 1G Eth
loopback and FANs full speed (8 m/s intake)
*Note – 17A transient currents observed with the
system at full benchmark performance. Proper input
power supply margin is required.
12
V
108
W (RMS)
50°C (typ.)
