23
GP_Out_1
GP_In_1
24
25
GP_Out_2
GP_In_2
26
27
GP_Out_3
GP_In_3
28
29
PWM_Out_0
PWM_Out_1
30
31
GND
GND
32
33
RS232A_TX/
RS485A_TXP
RS232A_RTS/
RS485A_TXN
34
35
RS232A_RX/
RS485A_RXP
RS232A_CTS/
RX485A_RXN
36
37
RS232B_TX/
RS485B_TXP
RS232B_RTS/
RS485B_TXN
38
39
RS232B_RX/
RS485B_RXP
RS232B_CTS/
RS485B_RXN
40
Notes:
All I/O are 3.3V unless otherwise specified.
GP_Out_x - are driven outputs and can sink or source 12mA
GP_In_x - VIH (Input High Voltage minimum) = 2V. No pullup or
pulldown is pre-configured, user discretion to add externally if
required for their application.
PWM_Out_x - are driven outputs and can sink or source 24mA
3V3 Power output can provide up to 1A of current.
