Operating Manual PG11 / PGE11 Page 32
recalibrated by the operator.
WARNING
Minor issue [#warn]
Please contact vendor and supply the #warn code. Detector is still
measuring gas inside specification, but the vendor should be
informed to verify status.
SERVICE
SERVICE MODE
Detector is in service mode and does not detect gas.This is due to
the detector being set to service mode for example during testing,
change of settings, loop testing or other services manually started.
SERVICE
BOOT
Detector is booting up.
SERVICE
WARM UP
Arctic detector is warming up electronics at extreme temperatures
before booting up the rest of the electronics.
7.2 Light indicator
The PG11 has a built in multicolour light indicator with the following settings:
Status type
Indicator
Description and typical applications
Normal
Operation
GREEN
Detector is Measuring gas and no issues detected.
Maintenance
Request
GREEN
BLINKING
Optics is getting dirty and it is recommended to clean it soon. Detector
is still detecting gas inside specification.
Out of
Specification
GREEN
BLINKING
Signalled if temperature is above or below rating of this Detector.
Detector will measure gas, but the accuracy of the Gas Detection
might be outside specification.
Function Check
YELLOW
Activated if the Operator has set the detector into Service mode.
Failure
YELLOW
BLINKING
No gas detection due to one of the following:.
• Detector is booting up
• Beam Block
• Faulty detector
Alarm 1
RED
Gas concentration is above the first alarm set point.
Default setting: 20% FS - non-latching.
Alarm 2
RED
BLINKING
Gas concentration is above the highest gas alarm set point.
Default setting: 20% FS - non-latching.
