SECTION 4 OPERATING INSTRUCTIONS
This appliance is NOT intended for use by young children or infirm persons
without supervision.
To set up unit for operation after unpacking and checking for damage proceed
as follows:
1) Follow any installation procedures (See SECTION 3).
OPERATING CONTROLLER:
This example will demonstrate how to set the cabinet for the following
conditions:
Temperature = 37.0
o
C Carbon Dioxide = 5.0%
TO SET TEMPERATURE
Press and hold the TEMP button. The display will blank for 2 seconds, release
the button. The SET LED above the temperature display will turn on indicating
that this parameter is now in the temperature set mode and the current set point
will be displayed. Use the UP and DOWN buttons to adjust the Set Point to
37.0
o
C.
When the adjustment is complete the controller will return to normal operation if
the buttons are not pressed. This is indicated by the TEMP SET LED going off.
TO SET THE CO
2
CONCENTRATION
Press and hold the CO
2
button. The display will blank for 2 seconds, release
the button. The SET LED above the CO
2
display will turn on indicating that this
parameter is now in the set mode and the current set point will be displayed.
Use the UP and DOWN buttons to adjust the set point to 5.0%.
When the adjustment is complete the controller will return to normal operation if
the buttons are not pressed. This is indicated by the CO
2
SET LED going out.
HEPA FILTER (If Fitted): To change the HEPA Filter, undo the two
knurled nuts holding the filter to the inside top tray and withdraw the
filter.
RELATIVE HUMIDITY
There is no electronic control of humidity in these enclosures, the humidity is
maintained either by placing a small plastic tray of water in the tray support and
attaching this to a vacant shelf ladder near the bottom of the cabinet or by
partially filling the large stainless tray on cooled units. The humidity level will
usually equilibrate to a relative humidity of above 80%. (typically 60% - 70% on
Tropicool and Cooled units.
