MANUALP/4000_SERVICE_0712 July2012
63
7. Re-mount the door back with the new gasket to the door front assembly.
For common reference, below is a cutout photo of how the gasket is
held between the door front and back assembly. The pop rivets will hold
the gasket through the door front and back assembly.
8. Refit the cabinet main door.
Magnet
To Next Page
