212-M-V2.1
12 Operation
Three key switches provide the following functions:
Displays the accumulated (non-resettable) totals
for Energy, Volume, operating time (elapsed
time) and Energy total for log entries.
Also changes digits, decimal point or units
when entering the set-up parameters. A
flashing digit, decimal point or unit will
indicate that the parameter can be changed.
If the Reset function is enabled during set-up,
the RESET key, when held for 5 seconds, will
reset all totals and the operating time.
Also increments the digit, changes decimal
point position, steps through units when
entering set-up parameters and steps through
individual log entries.
Used to change the display to the next parameter.
Also steps through display modes when held for
5 seconds.
RESET
DISPLAY
ACCUM
TOTAL
