Contrec 212 - Peak and Off-Peak Operation

212-M-V2.1
18 Operation
3.1.3 Peak and Off-Peak Operation
If Peak and Off-Peak operation is programmed, the following display formats
will be apparent in place of the normal ENERGY display:
Peak Energy default display - Peak
Energy measured since the last reset.
Press DISPLAY Press ACCUM TOTAL
Accumulated Peak
Energy Total
(non-resettable).
Off-Peak Energy measured since the
last reset.
Press DISPLAY Press ACCUM TOTAL
Accumulated Off-Peak
Energy (non-resettable).
Display segments test. Segments are
flashing.
Press DISPLAY
For continuation of displays refer to Section 3.1.1 Normal Operation.
1 2 3 4 5 . 7
EN pk KWH
7 8 9 1 0 1 . 8
ACCUM KWH
8 8 8 8.8.8.8
TEST 00.0.0.0.
1 4 3 4 . 6
en opk kwh
6 4 3 2 6 . 5
ACCUM kwh
