3.1.2 Charge/Discharge Operation
If Charge/Discharge operation is programmed, the following display formats
will be apparent in place of the normal ENERGY display:
1 2 3 4 5 . 7
Charge Energy default display -
Charge Energy measured since
the last reset.
Press DISPLAY
Press ACCUM TOTAL
Accumulated Charge
Energy Total
(non-resettable).
Discharge Energy measured since
the last reset.
Press DISPLAY Press ACCUM TOTAL
Accumulated Discharge
Energy (non-resettable).
Press DISPLAY Press ACCUM TOTAL
Display segments test. Segments
are flashing.
Press DISPLAY
For continuation of displays refer to Section 3.1.1 Normal Operation.
EN chr KWH
7 8 9 1 0 1 . 8
ACCUM KWH
8 8 8 8.8.8.8
TEST 00.0.0.0.
1 4 3 4 . 6
en dis kwh
6 4 3 2 6 . 5
ACCUM kwh
