10 Specifications
Disclaimer: Control Microsystems reserves the right to change product specifications without
notice. For more information visit www.controlmicrosystems.com .
10.1 General
I/O Terminations
6,8,9 and 10 pole, removable terminal blocks.
12 to 22 AWG
15A contacts
Dimensions
SCADAPack
8.40 inch (213mm) wide
6.13 inch (155mm) high
2.80 inch (72mm) deep
Packaging
corrosion resistant zinc plated steel with black enamel paint
Environment
5% RH to 95% RH, non-condensing
–40
o
C to 70
o
C
–40
o
F to 158
o
F
10.2 Communications
Communication
Ports, 5203
controller board
2 RS-232 serial ports (COM1, COM2)
Data Terminal Equipment (DTE)
DE-9P male connector
Communication
Ports, 5204
controller board
One RS-232 serial port (COM2)
Data Terminal Equipment (DTE)
DE-9P male connector
One RS-485 serial port (COM1)
2 wire half duplex
4 wire full or half duplex
optional termination resistors
Communication
Ports
5604 I/O
Modulue
one RS-232 serial port (COM3)
Data Terminal Equipment (DTE)
DE-9P male connector
5604 I/O
Module
one RS-232 serial port (COM3)
Data Terminal Equipment (DTE)
8 pin modular jack
Baud Rates
(COM1, COM2)
300, 600, 1200, 2400, 4800, 9600, 19200, 38400
default: 9600
Baud Rate
(COM3)
Where applicable
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
Default: 9600
Parity
none, even, or odd
Default: none
Word Length
7 or 8 bits
Default: 8 bits
