Control Microsystems 5604 - Input 8; Analog Outputs

5604 Input/Output (I/O) Module - Hardware Manual
October 19, 2007
31
Type
single ended
Calibration
Calibration constants stored in on board
microcontroller EEPROM.
Normal mode rejection
26 dB at 50/60 Hz Maximum filter setting
21 dB at 50/60 Hz Medium filter setting
14 dB at 50/60 Hz Minimum filter setting
5 dB at 50/60 Hz No filter
Over-scale Input Capacity
Measures up to 10V/40mA
Inputs clamped between 12 and 17V
Transient: 2.5kV surge withstand capability as
per ANSI/IEEE C37.90.1-1989
Isolation
Analog common side connected to Chassis
Ground
Response Time
For 90% signal change, 60/50Hz.
155/185ms Maximum filter setting
85/ 95ms Medium filter setting
45/ 55ms Minimum filter setting
30ms No filter
10.5.2 Input 8
Input Points
1 at 0-32.768V
Resolution
10 bits over the 32.768V measurement range
Input Resistance
600k for 32.768V inputs
Converter type
10 bit successive approximation
Accuracy
±0.25% of full scale at 25
o
C (77ºF)
±1% over temperature range
Type
single ended
Calibration
Calibration constants stored in on board
microcontroller EEPROM
Over-scale Input Capacity
(without damage)
Transient: 2.5kV surge withstand capability as
per ANSI/IEEE C37.90.1-1989
Isolation
Analog common side connected to Chassis
Ground
Response Time
30ms for 90% signal change.
10.6 Analog Outputs
Output Points
2 (when optional 5305 analog output module installed)
Output Signal
Range
0-20mA
Maximum Load
Resistance
925 with 24Vdcinput voltage or when internal 24V power
supply is on.
375 with 12Vdc input voltage
250 with input voltage at power supply turnoff
Output Type
Single ended regulation on positive side with common
negative return
