Stop Bits
1 or 2 bits
Default: 1 bit
Duplex (COM1,
COM2)
full or half with RTS/CTS control
Default: full
Duplex (COM3)
half with RTS/CTS control
Cable Length
RS-232 –maximum 50 ft (15.2 m)
RS-485 –maximum 4000 ft (1200 m)
Protocol 5203
and 5204
Controller
Boards
TeleBUS (compatible with Modbus RTU and Modbus ASCII)
DF1 and DNP Protocols optional
Default: Modbus RTU
Protocol Modes
5203 and 5204
Controller
Boards
slave, master, master/slave, store and forward
10.3 Visual Indicators
Digital I/O
(5604 I/O Module)
32 red LED’s
Push-button
LED power toggle
10.4 Power Supply
DC power Input
30V maximum
11V minimum
12V at 5mA during Sleep Mode
12V at 10mA with no loading on the boosted 24V Vloop
12V at 550mA with 88% efficiency 23V/0.25A loading
24Vdc Power
Output
22.5 to 25.2 Vdc with 0 to 0.25A load.
Shutdown current limiting typically 0.36A.
Efficiency 88-92%, 12V on DC PWR input
5V power
required
170mA with LED’s enabled and all I/O on
15mA with LED’s enabled and all I/O off
15mA with LED’s disabled
10.5 Analog Inputs
10.5.1 Inputs 0-7
Input Points
8 at 10V/20mA: 250 resistance, user
configurable with jumper link
Resolution
15 bits over the 10V measurement range
14 bits over the 20mA measurement range
Input Resistance
20k for 10V inputs
250 for 20mA inputs
Converter type
16 bit successive approximation
Accuracy
±0.1% of full scale at 25
o
C (77ºF)
±0.2% over temperature range
