44 Commander SK Size 2 to 6 Getting Started Guide
www.controltechniques.com Issue Number: 2
Determines the input on terminal T2
0-20: Current input 0 to 20mA (20mA full scale)
20-0: Current input 20 to 0mA (0mA full scale)
4-20: Current input 4 to 20mA with current loop loss (cL1) trip (20mA full scale)
20-4: Current input 20 to 4mA with current loop loss (cL1) trip (4mA full scale)
4-.20: Current input 4 to 20mA with no current loop loss (cL1) trip (20mA full scale)
20-.4: Current input 20 to 4mA with no current loop loss (cL1) trip (4mA full scale)
VoLt: 0 to 10V input
In the 4-20 or 20-4mA modes (with current loop loss) the drive will trip on cL1 if the input reference is below 3mA. Also, if the drive trips on cL1, the
voltage analogue input cannot be selected.
If both analogue inputs (A1 and A2) are to be set-up as voltage inputs, and if the potentiometers are supplied from the drive’s +10V rail (terminal T3),
they must have a resistance >4kΩ each.
OFF: Direction of rotation controlled by run forward and run reverse terminals
On: Direction of rotation controlled by preset speed values (use run forward terminal)
Defines preset speeds 1 to 4.
Ld: Active current as a % of motor rated active current
A: Drive output current per phase in A
Fr: Drive output frequency in Hz
SP: Motor speed in rpm
Cd: Machine speed in customer defined units (See Pr 24).
Multiplying factor on motor speed (rpm) to give customer defined units.
Used to set-up a user security code. See section 5.6 Security codes on page 37.
0: keypad reference is zero
LASt: keypad reference is last value selected before the drive was powered down
PrS1: keypad reference is copied from preset speed 1
No Function Range Defaults Type
16 Analogue input 1 mode
0-20, 20-0, 4-20, 20-4,
4-.20, 20-.4, VoLt
4-.20 RW
No Function Range Defaults Type
17 Enable negative preset speeds OFF or On OFF RW
No Function Range Defaults Type
18 Preset speed 1
±1500 Hz
(Limited by setting of Pr
02 Maximum set speed)
0.0 RW
19 Preset speed 2
20 Preset speed 3
21 Preset speed 4
No Function Range Defaults Type
22 Load display units Ld, A Ld RW
No Function Range Defaults Type
23 Speed display units Fr, SP, Cd Fr RW
No Function Range Defaults Type
24 Customer defined scaling 0 to 9.999 1.000 RW
No Function Range Defaults Type
25 User security code 0 to 999 0 RW
No Function Range Defaults Type
26 Not used
No Function Range Defaults Type
27 Power up keypad reference 0, LASt, PrS1 0 RW
NOTENOTE
NOTENOTE
