Convotherm OEB Series User Manual

Service manual OEB/OES/OGB/OGS
5_00e Troubleshooting list_L 20/27 2013-01-30
OEB OES OGB OGS
Defect Possible cause or remedy
time you switch on the device.
basic screen:
 refer to procedure described in 5.8.3.








5.8.5
After changing the EasyTouch
control panel, the automatic
cleaning process does not
start.
The display shows this:
'Cleaning running', but no
program function or elapsing
of time.
 Software version on the control module and
easyTOUCH control do not match.
 Click the gear wheels -
 Click Service -
 Enter password, '1gaz' -
 go to the I/O tab
 Click Update SM bottom left
 Double-click in Flash-Disk menu,
 ECP7000 - double click
 SM.bin - double click
 Select 'Update SM'








5.8.6
The display responds audibly
to contact (click) but the
screen lighting remains off
(dark screen)
 On the TX 18, check the voltage in the 12V
supply module and increase by 10% if
necessary.
 On TX18 and LED version, check that the grey
ribbon cable is properly located.
 High-voltage inverter defective








5.8.7
easyTOUCH control starts up
normally but does not respond
to touch contact (no click)
 On TX18 and LED version, check that the 4-
pin brown ribbon is properly located, and
inspect for signs of damage.








5.8.8
After the system has been
switched on, a blue screen
appears with a
grey window:
' easyTOUCH.exe - error'
 easyTOUCH software is damaged.
 Use Quit (possibly click Details and make a
screenshot and/or take a picture of this and
report to Convotherm for troubleshooting
purposes) to confirm and to close the grey
pop-up window.
 Run the software update as described in the
service manual, otherwise run the update
manually as described in Point 5.8.1.








5.8.9
easyTOUCH control
completely non-functional
after replacement
All telltale LEDs are not lit
 Check the 12V power supply on the
easyTOUCH control unit
 The polarities of the power supply connector
on X4 Plus (red) and negative (blue) must not
be reversed.








5.8.10
After the unit is switched on,
only a grey screen without
symbols appears.
 Graphics ribbon cable not plugged in correctly.
 Check power supply
 Failing that, replace the easyTOUCH control
panel








5.8.11
The USB slot does not
function at all. USB stick is not
detected.
 Check cable connection to USB port. USB
cable may have slipped out.
 Remove easyTOUCH panel and try the USB
port once again, this time directly on the
easyTOUCH panel.
