Service Handbook OEB/OES/OGB/OGS
Clean the condenser with CONVOTHERM CONVOClean new or
CONVOClean forte and using the hand shower flush thoroughly afterwards
with water. With heavy build up in the condenser, perform an additional
chemical descaling with CONVOTHERM CONVOCAL (Process for descaling
according to instructions as described in 4.4.3).
Instructions – Condenser installation:
Hang the condenser 7 into the connection area onto the fastening brackets
and screw tightly in with the Stop nut M6 15 and underlaying washer 3.
Set the condenser (7) with new O-Ring (6) (smear with lubricant i.e.
vegetable oil) onto the oven drain, pull it high up into the oven and fasten onto
the holder cross 4. and the hexagon screw 2 with washer 3. Pull the hexagon
screw 2 far enough until the holder cross 4 sets on the soldered nut of the
condenser floor.
Assemble all the connections in the connection area onto the condenser 7:
- Set breather pipe 17 onto the pin and tighten hose fitting 16
- Screw in condenser probe B3 8 with new seal 9
- Screw in the angle hose connection 18 and insert nozzle 19 for cooling
in the condenser 7
– Screw on
bypass gauge pipe 13 with copper seal 14
- Set the hose 11 to the unit drip tray onto the pins and fasten with cable
binder 10 (only on table units).
Set the cover 1 onto the demoisturizing tub again and hang the left shelf rack
into the oven again.
Hang the floor clap 21 onto the right side of the outer floor 20, clap it upwards
and fasten the floor clap 21 with 2 screws M5 (cross width SW 8 or phillips
screwdriver) and washer 22 on the motor side.
Attention:
Always use a new O-ring part no.: 6015000 by every removal and installation
of the condenser.
Cross reference:
Installation Handbook 1. Installation
Service Handbook 4.3 Cleaning the unit
AS/11-2011 6_11e_Condenser removal and installation_b
Page 2 / 3
