Convotherm OEB Series User Manual

Service Handbook OEB/OES/OGB/OGS
AS/11-2011 6_17e_Inner and outer door replacement_b
1 = Outer d
oor
2 = Slot panel
3 = Upper hinge plate (fastened onto the slot panel with washer, spring washer
and screw)
4 = Lower part of the upper hinge plate
5 = Lower hinge plate
6 = Stop plate
Notice:
 Using a marker, mark the setting of the hinge plate stop before disassembling.
 The distance of the door to the front piece can be adjusted with the hinge
plate stop.
Page 4 / 4
