6.17.3 Replacing outer door on table and standing units
Check:
 Scratches on the glass panel of the outer door
 Panel is broken
Safety:
 Maintenance and repair work should only be performed on a cold unit.
 Do not open inner door at temperatures > 80°C.
 Secure the screws with screw locking lacquer ( i.e. Loctite).
Instructions – Removing the outer door:
 Remove the inner door 2 (see 6.17.1 and 6.17.2 Instructions for table and
standing units).
 Mark the setting of the upper hinge plate with a marker before removing.
 Holding the door, unscrew the screws and remove hinge plate.
 Lift the door up and out of the hinge.
Instructions – Replacing the outer door:
 Lower the door onto the setting.
 Place the upper hinge plate in the door and fasten it with washer, spring
washer and screw onto the slot panel - don’t tighten yet!
 Place the hinge plate on the marked setting and tighten screw.
 distance of closed door to front piece = 10 mm
 door upper edge must be horizontal.
Secure the screw with screw locking lacquer i.e. Loctite.
 Assemble the inner door 2 again (see 6.17.1 and 6.17.2 Instructions for table
and standing units).
AS/11-2011 6_17e_Inner and outer door replacement_b
Page 3 / 4
