Service manual OEB/OES/OGB/OGS
Hints:
The initial letters of the service numbers have the following meaning:
 r-- = read value  read access only
 c-- = control value  read and write access (function parameter)
 d-- = diagnosis value  is used for troubleshooting and
function control:
Page 2 / 6
Cross reference:
 Service manual 5. Troubleshooting list and error messages - Electronics
Service no.: Description
Plug
Pin
OES 6.06
OEB
OES
OGB
OGS
Minimum
settin
g
Maximum
settin
g
Default value
Unit
Comments
r01 Core temp. sensor 1
X16 2+6






 
°C
Current temperature
r02 Core temp. sensor 2
X16 3+6






 
°C
Current temperature
r03 Core temp. sensor 3
X16 4+6






 
°C
Current temperature
r04 Core temp. sensor 4
X16 5+6






 
°C
Current temperature
r05 Oven temperature
X16 7+8






 
°C
Current temperature
r06 Bypass temperature
X16 9+10





 
°C
Current temperature
r07 Condenser temperature
X16 11+12






 
°C
Current temperature
r08 Steam generator temperature
X17 1+2







°C
Current temperature
r09 STL temperature
X17 3+4







°C
Current temperature
r10 not used





r11 not used





r12 not used





r13
Electronics temperature
(sensor is located on the electronics)






 
°C
Current temperature
r14 Ident Gas







1
Saved in the IDM
r15 Ident Elect.








1
Saved in the IDM
r16 not used





r17 not used





r18 Cleaning agent pressure
X15 6+7





 
Pressure switch S2
CONVOClean system
1 = Pressure present
r19 not used





r20 Bottom level
X15 2







0 = Level not reached
1 = Level reached
r21 Upper level
X15 1







0 = Level not reached
1 = Level reached
r22 Motor TP (Thermoprotection)
X11 1+2





 
Not with Single Phase
r23 Door contact
X15 4+5






 
0 = Door open
1 = Door closed
r24 Status FC1







0 = Error free
r25 Status FC2







0 = Error free
r26 Status gas module







0 = Error free
r27 Speed of fan 1



 
RPM
r28 Speed of fan 2



 
RPM
AS/11-2011 3_01e Customer service - Service programme_f
