Convotherm OEB Series User Manual

Service manual OEB/OES/OGB/OGS
3.5 Controller assignment diagram
3.5.1 Control module (CM)
in the OEB and OES
Page 1 / 4
CM
A
rticle no. 5012004
A
rticle no. 5012003
A
rticle no. 5002094
X13
X17
X16
A
rticle no. 5002094
X14
14 not used
13 not used
12 not used
11 not used
10 not used
9 not used
8 not used
7 GND
6 Pressure cleaning
5 GND
4 Door
3 GND
2 not used
1 Water pressure
OES
Communication port
Article no. 5009315
OEB - OES
OEB - OES
1 SG pump (OEB)
2 Main cont
actor
3 SV water nozzle 4 Pump C. Care 5 not used 6 Pump cleaning agent 7 D
(Sicotronic) N
8 C
(Sicotr.) load contactor
9 B
(Sicotr.) thermostat
10
A
(Sicotronic) phase
1 Auxiliary fan (-)
2 Auxiliary fan (+)
3 12V
4 Earth
5 Earth
6 RxD_12V
7 TxD_12V
8 not used
9 IDM bk
10 IDM wt
11 IDM bl
12 IDM rd
Frequency converter
*²
OEB - OES
1 Thermop. Motor *
2 Thermop. Motor *
3 Motor anti-clockwise *
4 Motor clockwise *
5 Motor fast *
6 Motor slow *
7 Hot air 2
8 Steam generator 2
X11
OEB
1 Thermop. Motor *
2
Thermop. Motor *
3 Motor anti-
clockwise *
4 Motor clockwise *
5 Motor fast *
6 Motor slow *
7 Hot air 2
8
t d
A
rticle no.
OES
1 Phase
2 Oven light
3 Hot air 1
4 Steam generator 1
SG
5 SV condenser
6 SV demoisturising
7 SV SG filling
X12
OEB
1 Phase
2 Oven
light
3 Hot air 1
4 SV injection
5 SV condenser
6 SV demoisturising
7 not used
OES
12 (-)
11 Condenser
10 (-)
9 Bypass
8 (-)
7 Oven
6 (-)
5 CTS4
4 CTS3
3 CTS2
2 CTS1
1 ESD protection (CTS-
OEB - OES
10 (-)
9 not used
8 (-)
7 not used
6 (-)
5 not used
4 (-)
3 STL SG
2 (-)
1SG
OEB - OES
14 not used
13 not used
12 not used
11 not used
10 not used
9 not used
8 not used
7 GND
6 Pressure cleaning
5 GND
4 Door
3 GND
2 Bottom level
1 Upper level
OEB
not used
not used
not used
not used
not used
not used
not used
not used
not used
not used
OEB - OES
X18
X19
X10
A
rticle no. 5012003
X15
A
rticle no. 5012003
A
rticle no. 5012001
* = not used with frequency converter (single
phase)
*²
AS/11-2011 3_05e Controller assignment diagram _d
