Service manual OEB/OES/OGB/OGS
AS/11-2011 3_05e Controller assignment diagram _d
3.5 Controller assignment diagram
3.5.4 Control module CM
with the OES 6.06
Page 4 / 4
Communication port
X18
Article no. 5009315
X17
not used
not used
not used
not used
not used
not used
not used
not used
not used
not used
14 not used
13 not used
12 not used
11 not used
10 not used
9 not used
8 not used
7 Demoisturisation flap - S2
6 not used
5 GND - S7
4 Door - S7
3 GND - S1
2 Demoisturisation flap - S2
1 Water pressure - S1
12 (-)
11 Condenser
10 (-)
9 not used
8 (-)
7 Oven
6 (-)
5 CTS4
4 CTS3
3 CTS2
2 CTS1
1 ESD protection (CTS-GRD)
10 (-)
9 not used
8 (-)
7 not used
6 (-)
5 not used
4 (-)
3 not used
2 (-)
1 not used
A
rticle no. 5012004
X19
1 Auxiliary fan (-)
2 Auxiliary fan (+)
3 12V
4 Earth
5 not used
6 not used
7 not used
8 not used
9 IDM bk
10 IDM wt
11 IDM bl
12 IDM rd
X10
1 Phase
2 Oven light
3 Hot air 1
4 SV injection
5 SV condenser
6 not used
7 not used
1 not used
2
not used
3
not used
4
not used
5 Motor
6
not used
7
not used
8
not used
1 not used 2 not used 3 not used 4 not used 5 not used 6 not used 7 not used 8 not used 9 Motor demoisturisation flap 10 + 12 V
X14
A
rticle no. 5002094
X15 X11
X12
X13
A
rticle no. 5002094
A
rticle no. 5012003
A
rticle no. 5012003
X16
A
rticle no. 5012003
A
rticle no. 5012002
A
rticle no. 5012001
CM
