Summary
32
EN
Page
1. Safety advice 35
Description of functions, Designated applications,
Danger of accidents, Risk prevention
2. Positioning 37
Prerequisites for installation site, Transport to installation site,
Removing unit from pallet, Distancing / Positioning
3. Electrical connection (D) in Connection plan 39
Implementation, Electrical connection data
4. Water connection (A,B,C) in Connection plan 42
Water inlet, Water outlet
5. Gas connection (J) in Connection plan 44
6. Gas exhaust conduction (K,L) in Connection plan 46
7. Combustible air ventilation 47
8. Authorisation / Inspection 47
9. Checklist 48
Installation Check, User Information
10. Operation 52
Operation start up, Storage after use and disposal,
Instruciton of the users
11. Optional Equipment 53
Automatic Cleaning CONVOClean system, Stacking kit, Marine version,
Grilling version, connection of a communication interface, Ventilation hood,
Accessories and Options
12. Technical Data 60
13. Certificate and Declaration of conformity 92
14. Connection plans 94
The pictures and drawings for the respective chapters can be found on the fold-out pages in the
front and back of this manual. Dimensional drawings and connection plans can be found at the
end of the Installation instructions.
At the time of printing, this manual contains to the greatest possible extent all descriptions for
our combi steamer. Not all features are provided as standard. Subject to new technical
developments or modifications, and omissions.
