12. Technical Data
60
EN
• Unit data (K… to …R see drawing):
Model OES / OGS / OEB / OGB
Unit size 6.10 6.20 10.10 10.20 12.20 20.10 20.20
Type
Table unit Table unit Table unit Table unit Standing
unit
Standing
unit
Standing
unit
Standard container
[GN] 6x1/1 GN
6x2/1 GN
10x1/1
GN
10x2/1
GN
12x2/1
GN
20x1/1
GN
20x2/1
GN
Additional loading
possibilities*
[GN] 12x1/1
GN
20x1/1
GN
24x1/1
GN
40x1/1
GN
Shelf distance
[mm] 68 68 68 68 67 67 67
Approval seal, Protection
class
CE, IPX5
Material
Inner and outer construction of stainless steel, Material no. 1.4301
Noise level
[dB(A)] The noise commission level for the workplace is lower than 70 dBA
Hose length Hand shower
[mm]
2,050
2,050 2,050
2,200
2,200
2,200
2,600
(approx. value)
[l/h]
20-30
30-50 30-50
40-70
50-80
60-80
80-100
Rated capacity Steam
generator (approx. value)
Only for OEB
[kg/h]
12.6
21 21
31.4
37.8
37.8
50.4
Content steam generator
for OEB
[Liter]
6.5
9 9
12.5
12.5
12.5
17
M = oven width
mm 445 650 445 650 650 445 650
N = oven depth
mm 640 840 640 840 840 640 840
O = oven height
mm 492 535 760 760 956 1492 1492
P = width hinge side
mm 45 45 45 45 60 60 60
Q = sill height
mm 280 280 280 280 380 380 380
R = opening depth
mm 33 33 33 33 33 33 33
K = width with open door
90°
mm 1,160 1,160 1,160 1,160 1,260 1,260 1,260
K' = width with open door
180°
mm 1,850
1,868 1,850
1,868
1,990
1,990
1,990
L = protuberance with
door open
mm 50
50 33
33
55
55
50
Values for electrical units OEB & OES
Radiated heat output
[kJ/h]
6,804 12,247 12,247 21,384 21,384 24,494 42,768
Latent heat output
[kJ/h]
4,536 8,165 8,165 14,256 14,256 16,330 25,512
Values for gas units OGB & OGS
Sensible heat output
[kJ/h]
2,500 4,100
4,100 7,200 8,200 8,200 14,100
Latent heat output
[kJ/h]
2,100
3,500 3,500 7,100 11,000 7,100 11,000
Exhaust gas
[m
3
/h] 25
40 40 70 80 80 140
* = All units can also be loaded with baking pans at a shelf distance of 80 mm (78 mm on unit size
6.10).
