3. Electrical connection
41
EN
To comply with the required maximum ratings (see table above) in accordance with EN
61000-3-11 the required power impedances are to be notified to the local power supply
company!)!
Attention: always observe local ordinances!
• Gas appliances:
Model OGB
Unit size 6.10 6.20 10.10 10.20 12.20 20.10 20.20
3/N/PE ~ 400 V 50/60Hz
Connection power 400V [kW] 1.1 1.1 1.1 1.5 1.5 2.15 2.2
Rated current 400V [A] 2.9 2.9 2.9 3.5 3.5 5.0 5.4
Rated Connection
average *
[mm²] 5 x 1.5 5 x 1.5 5 x 1.5 5 x 1.5 5 x 1.5 5 x 1.5 5 x 1.5
1/N/PE ~ 220V - 240 V 50/60Hz
Connection power 230V [kW] 1.4 1.4 1.4 1.8 1.8 2.6 2.7
Rated current 230V [A] 4.9 4.9 4.9 6.1 6.1 9.0 9.4
Rated Connection
average *
[mm²] 3 x 1.5 3 x 1.5 3 x 1.5 3 x 1.5 3 x 1.5 3 x 1.5 3 x 1.5
Model OGS
Unit size 6.10 6.20 10.10 10.20 12.20 20.10 20.20
3/N/PE ~ 400 V 50/60Hz
Connection power 400V [kW] 1.0 1.0 1.0 1.4 1.4 2.0 2.1
Rated current 400V [A] 2.5 2.5 2.5 3.1 3.1 4.6 5.0
Rated Connection
average *
[mm²] 5 x 1.5 5 x 1.5 5 x 1.5 5 x 1.5 5 x 1.5 5 x 1.5 5 x 1.5
1/N/PE ~ 220V - 240 V 50/60Hz
Connection power 230V [kW] 1.3 1.3 1.3 1.7 1.7 2.5 2.6
Rated current 230V [A] 4.5 4.5 5.0 5.7 5.7 8.6 9.0
Rated Connection
average *
[mm²] 3 x 1.5 3 x 1.5 3 x 1.5 3 x 1.5 3 x 1.5 3 x 1.5 3 x 1.5
* Recommended connecting line laid open to the air for max. 5 m long!
Attention: always observe local ordinances!
