Cool Automation CoolPLug User Manual

CoolPlug CooLinkHUB HVAC Bridge Connecting CoolPlug HT (Hitachi)
QIG Version 2.2 16 CoolPlug CooLinkHUB
9. Connecting CoolPlug HT (Hitachi)
1 Connecting the CoolPlug to the Hitachi unit
Connect the CoolPlug’s HVAC [1], [2] terminals to the [1], [2] terminals on the indoor
unit.
2 Connecting the CoolPlug to the CooLinkHUB
Connect the signal wires of the PBUS cable coming from the [VDC-], [1] and [2]
terminals on the CooLinkHUB to the corresponding [-], [1] and [2] terminals on the
CoolPlug.
3 Optional: Connect the Wired Remote Controller (W.R.C.).
