16. Mounting the CoolPlug
On a Metal Surface
The CoolPlug back plate has two magnets
that allow you to mount it on any metal
surface.
On the Wall
Attach the CoolPlug back plate to the wall
using screws as shown. The wires can be
fed through the hole in the center of the
cover or from the side as shown.
On DIN Rail
Use back plate for DIN rail to attach it to the
DIN rail utilizing magnets.
