Coolerado M50C - Page 54

Coolerado Installation
Page 54 of 63
Installation Checklist
11. Have product air ducts been insulated and properly sealed? See Step 8 in Installation Manual
□
Yes
□
No
12. Has product air plenum been insulated and properly sealed? See Step 8 in Installation Manual
□
Yes
□
No
13. Is water connected and the field water piping to the unit appears to be correct per design
specifications?
See Step 9 in Installation Manual
□
Yes
□
No
14. What is building dynamic water pressure?
See Step 9 in Installation Manual
psi
15. Is a 30 micron cartridge filter installed on the water supply line? See Step 9 in Installation Manual
□
Yes
□
No
16. Have all electrical connections been tested for tightness? See Step 10 in Installation Manual
□
Yes
□
No
17. Does the electrical service correspond to the unit nameplate? See Step 10 in Installation Manual
□
Yes
□
No
18. What is the voltage to the unit?
See Step 10 in Installation Manual
Volts
19. Is water turned on? See Step 15 in Installation Manual
□
Yes
□
No
Post Installation Checklist
1. Are dip switch settings properly set per table? See Step 12 in Installation Manual
Dip switch
1
Power Failure Rewet; OFF< 1 Hr, ON 4
2
Water Quality, OFF good, ON poor
3
Model Number, factory set
4
Model Number, factory set
Elevation
0
2000’(610M)
4000’(1220M)
6000’(1830M)
5
Off
On
Off
On
6
Off
Off
On
On
7
On for Variable Speed Fan
8
On Freeze Protection
□
Yes
□
No
2. What is the dynamic water pressure (psig) at the HMX header? See Step 9 in Installation Manual
Is it set at 5.4 inches of water column?
psig
□ Yes □ No
