COOLIUS A50 - The Machine

11COOLIUS A50
3.2.2 The machine
1 LP pressure indicator
2 HP pressure indicator
3 Internal vessel pressure
gauge
4 Printer
5 Front cover
6 Rear wheel
7 Front wheel with brake
8 Drier lter
9 Main switch
10 Bottle for PAG oil
250 ml
11 Storage box for accesso-
ries
12 Bottle for POE oil 250
ml
13 Bottle for UV leakage addi-
tive 100 ml
14 Drained oil sealed bottle
250 ml
15 LP quick coupling
16 HP quick coupling
17 LP hose
18 HP hose
19 By-pass
20 Front pocket
21 Scale lift knob
22 Inlet port pressure test
(Max 12 bar)
23 Ventilation Security System
inlet grid
4
19
15
18
1 2
5
7
6
3
g. 002 Front view
16
17
20
8
22
9
11
g. 003 Rear view
21
23
g. 004 Left view
14
13
12
g. 005 Right view
10
