39COOLIUS A50
3. At the end, bring back the knob to the “working position” (turn it counter-clockwise, move it slightly up
and to the right, then fully down).
In case of mistake:
Perform again the procedure and be sure to follow
correctly the instructions!
6.7.2 Waste oil weight scale
1. Disconnect the waste oil bottle from its coupler.
2. Press START key to conrm bottle disconnected.
WARNING! Conrm by START only if the waste
oil bottle is disconnected!
3. Wait the end, then reconnect the waste oil bottle.
Reset not possible!
Scale not unloaded
PLS unload the scale
before reset.
Unload used oil
scale!
7 Technical features
Technical features COOLIUS A50
Power 230V+/-10% 50Hz
Operating temperature range 10/49 °C
Refrigerant R134a
Internal vessel capacity (Kg) 20 kg
Maximum pressure (PS) 20 bars
Compressor 3/8 HP
Recovery rate (liquid) 500 g/min’
Not condensable gas discharge Automatic
Main drier lter Type 660 Coaxial
Ventilation Security System 172 mm
Recovery high speed fan 172 mm
Internal vessel pressure gauge D40 mm
Oil discharge – Environment friendly Automatic
Bottle capacity (sealed) 250 ml
Refrigerant Weight scale 60 kg
Scale accuracy (+/-) 2 g
Nitrogen pressure test Automatic
Vacuum pump 128 lt/min
Final pressure (McLeod abs) 0,05 mb
Electronic vacuum meter YES
