Weatherproof Wall Sounder - MAS850LPS/WP
Installation
1. Drill required holes for the cable gland fixing
2. Drill out the required fixing holes
3. Fix to mounting surface using two suitable screws
Standard Connections
WARNING: Do not use high voltage testers if any equipment is connected to the system. earth
screen must be continuous along entire length of loop.
Section 5 - Appendix
Analogue addressable loop
In Out
E+-
E+-
