24
The Calibration screen is explained in detail in Section 6.3 Calibration via App on page 30.
Modbus Setup Screen
The following parameters can be set:
• Modbus address
• Baud rate
• Parity and stop bits
Pressing SET DEFAULT sets the default parameters shown in the table in the Modbus setup
paragraph (does not affect the Modbus address).
Test Mode Screen
If enabled, the following functions can be activated in test mode, specifically not
corresponding to the behavior of the device, rather for debugging.
• Warning relay
• Alarm relay
• Green LED
• Red LED
• Yellow LED
• Analog output
More Screen
Displays the app technical and legal information.
• App settings - change the unit of measure for the temperature displayed in the app.
• Device Info - view information on the currently connected device.
• Create report - make a copy of the most recent report generated.
• Change logo - replace the default logo that is shown on the calibration certificate with
a different one.
• Third party licenses - see information on the third-party licenses used.
