CopterX CX-CT6C - 3 Transmitter Chart; 4 Binding

3. Transmitter Chart
Antenna
03
CX-CT6C
2.4GHz 6 Channel FHSS Technology
Digital Proportional Radio System
Hover pitch Hover throttle
Digital trim
Digital trim
INCREASE
DECREASE
ENTER
Right stick
TH. Hold (Heli.)
CH 5 (Plane)
GYRO.SENS (Heli.)
CH 6 (Plane)
Digital trim
Digital trim
Power switch
LCD display
UP
DOWN
EXIT
Hook
Left stick
(Heli.) A/E/R DR
(Aile, Elev, Rudd)
IDLE switch
Charging jack
4. 2.4G Binding
The binding process: turn on the transmitter, then connect the power of receiver keeping the
receiver “BIND” button till the light turn on GREEN which means the binding is successful. After that,
it is unnecessary to bind again.
Caution: make sure the RX and TX is within one meter, and around 10 meters no similar device. If
the light flashing, showing the binding failure, please do again as above indication.
