Cord One - Introduction

4
Introduction
Item Parameters Description
Input Power supply Single-phase
Rated voltage 230V (1P+N+PE)
Rated current 32A
Frequency 50Hz
Output Output voltage 230V AC
Maximum current 32A
Rated power 7kW
User interface Charge connector Type 2 cable
Cable length 5m or 7m
Housing material Plastic PC 940
LED indicator RGB
RFID reader Mifare ISO / IEC 14443A with 2pcs
Start mode Plug & Charge / RFID card / APP
Communication Communication Wi-Fi2.4GHz/4G
Protocol OCPP1.6
Frequency bandwidth
2400-2483.5MHz(Wi-Fi)
13.553-13.567MHz(RFID)
Max RF output power <20dBm (-10dBW)
Safety Built-in RCD
protection
Embedded 6mA RDC-DD according to IEC 62955
Ingress protection IP65
Impact protection IK08
Electrical protection Penfaultprotection,Overcurrentprotection,Residualcurrent
protection,Surgeprotection,Over/Undervoltageprotection,Over/
Underfrequencyprotection,Overtemperatureprotection
Standard and
compliance
BSENIEC61851-1:2019,IEC62955,BSIEC61851-21-2:2021,
BSENIEC61000-6-1:2019,BSENIEC61000-6-3:2007+A1,
BS7671:2018-amd2:2022722.411.4.1(iv),EN300328V2.2.2:2019,
EN300330V2.1.1:2017,EN301489-1V2.2.3:2019,
EN301489-3V2.1.1:2019,EN301489-17V3.2.0:2017,
EN62311:2020,BS7671:2018-amd2:2022722.411.4.1(iv)
Environment Installation Wall mount/Stand mount
Working temperature -30°C~+50°C
Working humidity 5%~95%
Working altitude <2000m
Package Product dimension 344 x 192 x 100mm (H x W x D) Cable
Net weight 3.5kg for 5m / 4.1kg for 7m
Gross weight 4.9kg for 5m / 5.5kg for 7m
