C10/C20 Manual
ITEM
No.
DESCRIPTIONPART No.
1 58 1185 101 Top Cover
2 58 0435 015 Cooling Fan (6mm Bore)
3 13 6690 000 Impellor for Agitator
4 85 6005 818 Cover - Hole
5 80 0800 710 Peardrop Knob Threaded (301/6/7)
6a 58 0483 002 Dispense Tap BT50
6b 14 5225 201 Faucet for C-10 Cooler
6c 84 4206 111 Dalex 200 NFCF DH PN C10
7 58 1185 111 Cup Rest
8 58 1185 102 Drip Tray
9a 44 0000 205 Comp. Set FR7.5G HST
9b 44 0000 240 Comp. Set FF8.5GX HST 115v
10 58 1180 123 Condenser STFT 12218
11a 58 0410 187 Fan Motor 5W 230V M/TEK CCWSE
11b 58 0410 190 Fan Motor 5W 115V M/TEK CCWSE
12 44 0000 052 Fan Blade O/D 165mm 26" CCWSE SUCK
13 58 1174 007 Thermostat Superspot
14a 99 1180 126 Agit Motor Assy.
3
/
4
" Stack Gain
14b 99 2ZU618A No. 2 Pump Assy. EBM (306 only)
14c 06 0 050114 Agit. Mtr. Assy.
3
/
4
" Stack 115v
Not 99 0420 058 Start Relay (240v)
Shown
Not 99 0420 059 Start Capacitor (240v)
Shown
Not 99 0900 002 Compressor Fixing Assy
Shown
Not 58 1184 101 Mod to Mains Lead
Shown
10. C10 (48 1180 3XX/48 1180 4XX) SPARE PARTS LIST
