Cornelius C10 - C10 Spare Parts List (Models 1 XX;2 XX)

7
®
C10/C20 Manual
ITEM
No.
DESCRIPTIONPART No.
1 58 1185 101 Top Cover
2 58 0345 015 Cooling Fan (6mm Bore)
3 13 6690 000 Impellor for Agitator
4 85 6005 818 Cover - Hole
5 80 0800 710 Peardrop Knob Threaded
6a 58 0483 001 Dispense Tap/Faucet
6b 58 0483 002 Dispense Tap BT50
7 58 1185 111 Cup Rest
8 58 1185 102 Drip Tray
9a 44 0000 205 Comp. Set FR7.5G HST
9b 44 0000 240 Comp. Set FF8.5GX HST 115v
10 58 1180 100 Condenser
11 58 1174 007 Thermostat Superspot
12a 58 0410 176 Motor
3
/
4
" Stack Fan
12b 58 0410 185 Motor
3
/
4
" Stack 115v Fan
13 58 0431 018 Fan Blade 5" O/D CCWSE
14a 99 1180 110 Agitator Motor Assy.
14b 99 1180 113 Agit Motor Assy 115v
14c 58 1170 051 Pump Assy (No. 2)
Not 99 0420 058 Start Relay (240v)
Shown
Not 99 0420 059 Start Capacitor (240v)
Shown
Not 99 0900 002 Compressor Fixing Assy.
Shown
Not 58 1184 101 Mod to Mains Lead
Shown
8. C10 (48 1180 1XX/48 1180 2XX) SPARE PARTS LIST
